T3390-1

Product Detail

Thermoplastic Polyurethane

● Application: Foot wear, Accessories, Protective gear, Compound, Caster wheel etc.

● Description: Polyester-based TPU.

 Processing methods: Injection moulding.

● Characteristics: Excellent physical properties, Easy&stable processing, Hydrolysis resistance and reusable properties.

● Properties:

ItemValue
Yellow index(Yi) 1.5
Specific gravity(g/cm3)1.23
Hardness(Shore A)92±1
Tensile strength(Mpa) 37
100% Modulus(Mpa) 9.5
300% Modulus(Mpa)17
Elongation at break(%)580
Tear strength (KN/m) 132
Flowing beginning Point.(℃)193
Processing temperature(℃)195-215

● Processing & Guide

For optimum results, previous drying of the product 2-3 hours under 100~110℃ is advisable, in a hot air circulatory, vacuum desiccate-air dryer.

● Package & Storage

25kg/bag.

Never put opened packages exposed in open air for prolonged periods of time during processing. Because of the high moisture absorbing property, TPU products should be well stored in a dry, cool and shady area.

● Note

These are typical values and should not be used as specifications.
